Ids Denmed HDi 110 Intraoral Camera (Tv Model)

Features: AV Port Direct Connection, Plug & Play. Powerful Imaging System Chip for Capturing/Save/magnifying/Delete pictures. High-resolution CMOS sensor. Six imported LED lights and an Autofocus lens. Easy to switch from full screen and four quad display.
Key Specifications: Power: DC 5V + 0.5 (1A) Image Sensor: 1/4" HD CMOS Active Pixels: 1280 x 1024 (1.3MP) Frame Ratio: 30fps @720p Angle of view: 80° Lights: 6 LEDs Focus Range: 5mm∼35mm Memory: Saving more than 3000 pictures Resolution: Tv Mode: 640 x 480 (NTSC) USB Mode: 1280 x 720 (720p)
Packaging: 1 x Camera handpiece 1 x AV Cable 1 x Power adaptor 1 x USB Cable 1 x SD Card 50 x Disposable Sheets Manual
Direction to Use: Power On the Camera: Connect the intraoral camera to its power source using the provided DC 5V power supply. Connect to a TV: Use the AV port to connect the intraoral camera directly to a TV. Ensure that both the camera and the TV are powered on. Adjust Camera Settings: Familiarize yourself with the camera controls. This may include buttons or menus for capturing images, adjusting focus, and navigating through different modes. Capture Images: Position the intraoral camera in the patient's mouth to capture images of the desired areas. Use the camera controls to capture still images. Ensure proper lighting for clear visuals. Review Images: Check the captured images on the connected TV screen. Evaluate the quality and ensure that the images provide the necessary details for diagnosis and patient education. Switch Modes (Optional): If the camera supports different modes (e.g., TV mode and USB mode), follow the instructions to switch between them based on your needs. Magnification (If Applicable): If the camera has a magnification feature, use it to zoom in on specific areas for a closer examination. Adjust the focus as needed. Delete Unwanted Images: If there is an option to delete images on the camera, use this feature to manage your image storage and keep only relevant pictures. Power Off: When you have completed your imaging session, power off the intraoral camera and disconnect it from the TV.
Additional Info: No additional info provided
Warranty: 1 Year warranty against the manufacturing defect.
